Services We Offer
Fabrication
Hardchrome Engineering has a long history of success working in industries including Earthmoving, Power Generation, Steel and Mining. Our large Fabrication and Machine shop in Yallourn, LaTrobe Valley, Victoria with wide bays and high roof line lends itself very well to larger project and construction works - all under a single roof supported by overhead craneage up to 50 tonnes (single lift)
- Plate Guillotines up to 13mm thick and 4,900 wide.
- Plate Brake Press Capacity – 100T up to 1,700T x 9,500 long.
- Plate Punching Capacity – 140T, max 36mm plate and maximum single hole Ø 100mm.
- Plate Rolling up to 80mm thick and up to 3,500 wide with end setting. (Vertical & Horizontal machines).
- Profile Cutting machines up to 16,000 x 4,100 plate cutting size, multi head fuel gas, plasma, marking & drilling capacity.
- TIG welding up to 300 Amp capacity – MIG welding up to 650 Amp capacity, including pulse and STT.
- Semi-automatic MIG Bore Welding – 22mm up to 1,800mm diameter
- Submerged Arc welding up to 1500 Amp DC & 1200 Amp AC capacity, including twin wire & tandem arc process.
- Stress Relieving Furnaces – work size up to 6,000 x 5,000 x 3,600 high.
Ancillary Capacity (HES – Yallourn)
- Paint Shop – 60,000 long x 16,000 wide x 7,000 high.
- Abrasive Grit Blasting room – 37,500 long x 8,000 wide x 8,000 high.
- Overhead Cranes up to 50T single lift, 90T tandem lift.
- Degreasing Tanks – article sizes up to 1,500 kg x Ø 2,000 x 1,200 high.
- Transport Equipment – Prime movers and semi-trailers including step decks, widening floats & dollies for oversize and over mass goods.
- Lifting Equipment – Mobile cranes, Tractor cranes, Conventional & Side- loading forklifts from 1.5T to 60T.
- Access Equipment – Boom lifts, Scissor lifts, No-bolt scaffolding & specially made access / work platforms.
Highlights
Large bays with high roof line all under a single roof
Extensive Ancillary Services available on-site
Depth of experience in Industries including Power, Mining, Steel and Earthmoving
Running our own fleet of flatbed trucks for collection and delivery throughout Australia
